Waterproof power supply
Informations
EB SERIES Waterproof power supply
| No. | 型号Model | 功率 Power |
输出电压电流 Output Volt. | 输入电压Input Volt. | 产品尺寸
Product Size(mm) |
|
| 1 | HK-EB018 | 18W | 12V 1.5A | 24V 0.5A | 176-264V | 150*30*20 |
| 2 | HK-EB024 | 24W | 12V 2A | 24 1A | 176-264V | 150*30*20 |
| 3 | HK-EB036 | 36W | 12V 3A | 24V 1.5A | 176-264V | 169*30*20 |
| 4 | HK-EB048 | 48W | 12V 4A | 24V 2A | 176-264V | 181*40*22.5 |
| 5 | HK-EB060 | 60W | 12V 4.16A | 24V 2.08A | 176-264V | 196*40*22.5 |
| 6 | HK-EB075 | 75W | 12V 6.25A | 24V 3.1A | 176-264V | 196*40*22.5 |
| 7 | HK-EB100 | 100W | 12V 8.3A | 24V 4.16A | 176-264V | 195*45*35 |
| 8 | HK-EB120 | 120W | 12V 10A | 24V 5A | 176-264V | 195*45*35 |
| 9 | HK-EB150 | 150W | 12V 12.5A | 24V 6.25A | 176-264V | 215*45*35 |
| 10 | HK-EB200 | 200W | 12V 16.6A | 24V 8.3A | 176-264V | 215*67*41 |
| 11 | HK-EB250 | 250W | 12V 20.8A | 24V 10.4A | 176-264V | 215*67*41 |
| 12 | HK-EB300 | 300W | 12V 25A | 24V 12.5A | 176-264V | 245*75*41 |
| 13 | HK-EB400 | 400W | 12V 33.3A | 24V 16.6A | 176-264V | 245*75*41 |
| 14 | HK-EB500 | 500W | 12V 41.6A | 24V 20.8A | 176-264V | 292*75*41 |
Application
| Product Name | LED DRIVER(switching Power Supply) |
| Input Voltage | 100-265V |
| Output Current | 2.5A-33.3A |
| Output Voltage | 12V 24V |
| Model Number | HK-EB |
| Output Frequency | 47~63Hz |
| Output Type | Single |
| Application | LED Lighting Driver |
| Efficiency | 85% |
| IP Rate | IP67 Waterproof |
| Protections | Short Circuit Protection, Overcurrent Protection, Overvoltage Protection, Over Temperature Protection, Overloading Protection, Undervoltage Protection, Over Power Protection, Overcharging Protection |
